主要特点
无缝衔接的硬件和软件集成,高可靠性运行
弹性显示设置
简单易用的使用设计
简单排程和发布
支持丰富和多种内容
轻松简单的独立配置
内容资源 本地硬盘或网络远程服务器获得
视频文件格式 MPEG1/2, AVI, VOB, MOV, WMV, VC-1, H.264
Flash 文件格式 SWF
图片文件格式 JPG, TIFF, ICP, PNG, GIF, BMP, WMF
声音格式 WAV, SND, MP3, M4A
Web/Data Web URL
Text files
RSS news feed
屏幕支持 Single display, two clone displays, or two expanded displays, or two independent displays
Portrait or Landscape orientation
Presentation can be segmented to different screen layouts
Up to 9 display zones in each screen layou
播放效果 Scrolling text and emergency message
Image transition effect
Multiple languages
内容流量 Up to 2 x HD video zones or 1x Full HD video zones
Multiple shockwave flash, pictures, and scrolling text zones
管理功能 Web-based management with password access control
Multilingual management interface
Presentation management
Presentation scheduling
System event log
Presentation playing log
Presentation play/Pause/Stop control function
System reboot, Shutdown, Firmware upgrade
文档设计 Presentation layout and playlist editing function
Presentation and content file preview function
Presentation publish function
操作系统 Windows XP Embedded
主板 Intel® Core™ 2 Duo P8400 2.13GHz, 3MB L2 Cache
内存 1GB DDR2 SDRAM
存储设置 160GB SATA HDD
I/O 接口 1 x HDMI, 1 x DVI, 1 x DB15 VGA
1 x Audio line-out, 1 x S/PDIF
4 x USB
1 x RJ45 with LEDs for 10/100/1000Mbps Ethernet
2 x DB9 for RS-232
8 x GPIO terminal (4 in, 4 out)
2 x Antenna hole for WiFi and TV tuner
扩展 1 x Mini-PCIe for optional WLAN module
1 x Mini-PCIe for optional TV tuner module
电源供应 1 x 外接96W AC/DC 电源适配器
输入: 100~240VAC
输出: +12VDC
体积 280mm (W) x 210mm (D) x 40.4mm (H) (11" x 8.3" x 1.6") w/o mounting bracket
环境 操作温度: Ambient with air flow from 0 to 40°C
存储温度: -40 to 80°C
相对湿度: 10 to 90% (Non-condensing)
认证 CE approval
FCC Class A
|
