主要特点 无缝衔接的硬件和软件集成,高可靠运行 弹性显示设置 简单易用使用设计 简单排期和信息发布 支持丰富和多种内容 轻松简单的独立配置
内容资源 本地硬盘或远程网络服务器获得 视频文件格式 MPEG1/2, AVI, VOB, MOV, WMV, VC-1, H.264 Flash 文件格式 SWF 图片文件格式 JPG, TIFF, ICP, PNG, GIF, BMP, WMF 声音格式 WAV, SND, MP3, M4A Web/Data Web URL Text files RSS news feed 屏幕支持 Single display, or two clone displays Portrait or Landscape orientation Presentation can be segmented to different screen layouts Up to 9 display zones in each screen layout 播放效果 Scrolling text and emergency message Image transition effect Multiple languages 内容流量 Up to 2x HD video zones, or 1x Full HD video zone, or 1x shockwave flash zone Multiple pictures and scrolling text zones 管理功能 Web-based management with password access control Multilingual management interface Presentation management Presentation scheduling System event log Presentation playing log Presentation play/Pause/Stop control function System reboot, Shutdown, Firmware upgrade 文档设计 Presentation layout and playlist editing function Presentation and content file preview function Presentation publish function 操作系统 Windows XP Embedded CPU Intel® Atom™ N270 1.6GHz, 512KB L2 Cache 内存 1GB DDR2 SDRAM 存储设施 160GB SATA HDD I/O 接口 1 x DVI-D, 1x DB15 VGA 1 x Audio line-out 4 x USB 1 x RJ45 with LEDs for 10/100/1000Mbps Ethernet 1 x DB9 for RS-232 电源供应 1 x 外接 60W AC/DC 电源适配器 电源输入: 100~240VAC 电源输出: +12VDC 体积 272mm (W) x 195mm (D) x 44mm (H) (10.7" x 7.7" x 1.7") w/o mounting bracket 环境 操作温度: Ambient with air flow from 0 to 40°C 存储温度: -40 to 80°C 相对湿度: 10 to 90% (Non-condensing) 认证 CE approval FCC Class A
|
